Honeywell 64 Channel 8-SATA 4K NVR | I-HPNVR-864

The Honeywell I-HPNVR-864 is a high-performance 64-channel Network Video Recorder (NVR) designed for enterprise-grade surveillance systems. With 8 SATA HDD support, ultra-high 640 Mbps bandwidth, multiple AI analytics, and advanced RAID support, it ensures powerful performance for large and mission-critical deployments.

🔑 Key Features

✔ 64 Channel IP Camera Support
✔ Supports up to 12MP Resolution Recording
✔ Ultra-High Bandwidth: 640 Mbps (In/Out)
✔ 8 SATA HDD Support (Up to 18TB Each – 144TB Total)
✔ Advanced H+265 / H.265 / H.264 Compression
✔ 4 × HDMI Output + VGA
✔ Dual Gigabit LAN Ports (2 × RJ45)
✔ RAID Support (0 / 1 / 5 / 6 / 10)
✔ Multiple AI Analytics Support

🎯 Video & Performance

• Video Input: Up to 64 Channels

• Maximum Resolution: Up to 12MP

• Incoming Bandwidth: 640 Mbps

• Outgoing Bandwidth: 640 Mbps

• High decoding capability for multi-camera monitoring

• Smooth real-time live view and playback

🖥 Video Output

• HDMI Output: 4 × HDMI (Up to 4K Resolution)

• VGA Output: Supported

• Multi-monitor display capability

• Screen Split Modes:
  1 / 4 / 8 / 9 / 16 / 25 / 36 / 64

💾 Storage

• HDD Interface: 8 × SATA Ports

• Capacity: Up to 18TB per HDD (Total up to 144TB)

• RAID Support:
  RAID 0 / RAID 1 / RAID 5 / RAID 6 / RAID 10

• Supports:
  ✔ NAS Storage
  ✔ FTP Backup
  ✔ Cloud Storage

• Smart compression reduces storage usage

🔄 Recording & Playback

• Recording Resolutions:
  12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 720P

• Multi-channel synchronous playback

• Smart event-based playback

• Video encryption supported

🌐 Network & Connectivity

• Ethernet Port: 2 × RJ45 (10/100/1000 Mbps)

• Supported Protocols:
  TCP/IP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, IPv4/IPv6

• ONVIF compatible (third-party cameras supported)

• Remote access via mobile app, CMS & web browser

🔌 External Interfaces

• USB Ports: USB 2.0 + USB 3.0

• Audio: 1 In / 1 Out

• Alarm: 16 In / 4 Out

• RS-485 & RS-232 supported

⚙️ AI & Smart Features

• Face Detection & Recognition

• Human & Vehicle Detection

• Line Crossing & Intrusion Detection

• Heat Map & Crowd Density Analysis

• Queue Management

• License Plate Detection

• Rare Sound Detection

⚡ Power

• Power Supply: AC 100–240V

• Designed for 24×7 continuous operation

🛡 Build & Design

• Rack Mount Enterprise Design (2U Class)

• Industrial-grade hardware

• Suitable for mission-critical deployments

• Operating Temperature: -10°C to +50°C

📐 Physical Specifications

• Dimensions: Approx. 440 × 460 × 89 mm

• Weight: ~6–8 kg (without HDD)

📦 Applications

✔ Smart City & Safe City Projects
✔ Airports & Metro Networks
✔ Large Industrial Facilities
✔ Data Centers & Warehouses
✔ Government & Enterprise Surveillance

💡 Why Choose I-HPNVR-864?

• Ultra-high 640 Mbps bandwidth for heavy workloads

• Massive storage with 8 HDD + RAID support

• Advanced AI analytics for smart surveillance

• 4 HDMI outputs for control room setups

• Reliable Honeywell enterprise solution
